GT Series
- High efficiency for high-pressure and close-temperature-approach applications.
Tailored for Heating and Cooling applications
Energy Heating and Cooling Product line plates
Heating and Cooling performance starts at the plate. Our designs are engineered to deliver efficient heat transfer, reliability, and long-term value in a wide range of applications.
Zachary He
Tranter Sales Director, HVAC
Thermal precision meets long-term operational value
The technology behind efficient heating and cooling systems
Tranter's Energy Heating and Cooling line plate series is engineered for demanding heating, cooling, and energy recovery duties across data centers, district energy networks, commercial buildings, heat pump systems, and industrial HVAC applications. Combining high thermal efficiency with a compact footprint and flexible design, the series helps operators reduce energy consumption, optimize system performance, and maximize reliability in critical temperature control processes.
AHRI Series
- Independently certified performance for greater project confidence.
GC and GL Series
- Flexible performance for pressure-drop-sensitive HVAC systems.
GX Series
- Optimized for unbalanced flows and maximum thermal efficiency.
HVAC line plates for
Data center cooling
The GT, selected GX, and AHRI plate series are designed for data center cooling applications where high thermal loads, energy efficiency, and reliable operation are critical. GT plates maximize heat transfer and support close temperature approaches, while selected GX configurations provide additional flexibility when flow conditions differ between cooling loops. With AHRI-certified designs, Tranter also offer independently verified thermal performance, giving operators confidence that cooling systems will perform as specified in mission-critical environments.
- Range: DN150-450
- Supports liquid cooling
- AHRI-certified options
GT and GX-plates for Data centers
Versatile, high-efficiency plate technology for demanding data center cooling applications.
| Size | Plates | ||||
|---|---|---|---|---|---|
| DN150 | GT-155 | GT-160 | GT-165 | GT-175 | |
| DN200 | GT-207 | GT-211 | GT-216 | ||
| DN300 | GT-305 | GT-315 | GT-325 | GX-205 | GX-265 |
| DN350 | GT-360 | GT-370 | GT-380 | ||
| DN450 | GT-420 | GT-430 | |||
AT-series for data centers
AHRI-certified plate technology for projects requiring validated thermal performance and minimum project risk.
| Size | Plates | ||||||
|---|---|---|---|---|---|---|---|
| DN150 | AC-052 | AT-155 | AT-160 | AT-165 | |||
| DN200 | AT-203 | AT-207 | AT-211 | AT-216 | AX-060 | AX-100 | AX-140 |
| DN300 | AT-303 | AT-305 | AT-315 | AT-325 | AX-085 | AX-145 | AX-205 |
| DN350 | AT-360 | AT-370 | AT-380 | ||||
| DN450 | AT-410 | AT-420 | AT-430 | ||||
| Double wall | ADW-016 | ADW-013 | ADW-026 | ADW-042 | |||
HVAC line plates for
HVAC Heating
The GT, GC, GL, and selected GX Series deliver reliable and efficient heat transfer for HVAC heating applications. Designed for various comfort heating, district energy interfaces, heat pumps, and building services systems, these plates help maintain stable temperatures, optimize energy use, and support long-term operational performance across a wide range of heating duties.
- Range: < DN100-300
- High-pressure design
- Ideal for HVAC heating
GC, GL, GX and GT-series for HVAC Heating
Optimized for HVAC heating, delivering reliable heat transfer and low pressure drop.
| Size | Plates | ||||
|---|---|---|---|---|---|
| < DN100 | GC-009 | GC-016 | GL-008 | GL-013 | |
| DN100 | GX-026 | GX-042 | GT-115 | ||
| DN150 | GT-155 | GT-160 | GT-165 | GT-175 | |
| DN200 | GT-207 | GT-211 | GT-216 | ||
| DN300 | GT-305 | GT-315 | GT-325 | GX-205 | GX-265 |
HVAC line plates for
HVAC Cooling
The GT and GX plate series is made to meet the cooling demands of modern HVAC systems. Engineered for efficient heat transfer and reliable operation, these plates help maintain precise temperature control, support energy-efficient system performance, and deliver long-term value across a wide range of commercial cooling applications. Available with AHRI-certified configurations, they provide independently verified thermal performance for greater confidence in system design and operation.
- Range: < DN100-300
- Low pressure drop
- AHRI-certified options
GT and GX-series for HVAC Cooling
Advanced plate geometry designed for efficient heat transfer in HVAC cooling systems.
| Size | Plates | ||||
|---|---|---|---|---|---|
| DN100 | GX-026 | GX-042 | GT-115 | ||
| DN150 | GT-155 | GT-160 | GT-165 | GT-175 | |
| DN200 | GT-207 | GT-211 | GT-216 | ||
| DN300 | GT-305 | GT-315 | GT-325 | GX-205 | GX-265 |
AT-Series for HVAC Cooling
AHRI-certified plate technology for reliable HVAC cooling and independently verified thermal performance.
| Size | Plates | ||||||
|---|---|---|---|---|---|---|---|
| < DN100 | AC-016 | AL-008 | AL-013 | ||||
| DN100 | AC-026 | AX-026 | AX-042 | AC-044 | AT-105 | AT-110 | AT-115 |
| DN150 | AC-052 | AT-155 | AT-160 | AT-165 | |||
| DN200 | AT-203 | AT-207 | AT-211 | AT-216 | AX-060 | AX-100 | AX-140 |
| DN300 | AT-303 | AT-305 | AT-315 | AT-325 | AX-085 | AX-145 | AX-205 |
HVAC line plates for
Light industries
The GT, GC, GL, and selected GX Series are designed to deliver reliable thermal performance across a wide range of light industrial applications. From process cooling and utility systems to general manufacturing operations, these plates provide efficient heat transfer, dependable operation, and the flexibility to support varying thermal and flow requirements.
- Range: < DN100-150
- Low pressure drop
- Built for industrial applications
GC, GL, GX and GT-series for light industries
Versatile plate design for efficient heat transfer in light industrial processes.
| Size | Plates | |||
|---|---|---|---|---|
| < DN100 | GC-009 | GC-016 | GL-013 | |
| DN100 | GX-026 | GX-042 | ||
| DN150 | GT-155 | GT-160 | GT-165 | GT-175 |
HVAC line plates for
Semi-conductors
The GT and GX plate series is engineered to support the precise thermal control required in semiconductor manufacturing. Designed for process cooling applications where temperature stability and reliability are critical, these plates deliver efficient heat transfer and dependable performance in demanding cleanroom and utility systems.
- Range: DN150-450
- Precise temperature control
- Designed for process cooling
GT and GX-series for semi-conductors
Reliable heat transfer for semiconductor cooling and temperature control applications.
| Size | Plates | ||||
|---|---|---|---|---|---|
| DN150 | GT-155 | GT-160 | GT-165 | GT-175 | |
| DN200 | GT-207 | GT-211 | GT-216 | ||
| DN300 | GT-305 | GT-315 | GT-325 | GX-205 | GX-265 |
| DN350 | GT-360 | GT-370 | GT-380 | ||
| DN450 | GT-420 | GT-430 | |||
Do you need help matching plates to your operational reality?
Contact us for more information!
